| Description |
I decided to consolidate 2 of my previous bikes into 1 in January 2022. I combined my lightest road bike and my gravel bike into a light gravel bike, which that was on the road side of the gravel spectrum. I wanted to keep on bike in my stable that allowed for wide gravel tires. |
I bought this frame as new old stock on eBay in July 2018. The idea was to get all my road bikes set up with di2 and reduce my road/gravel fleet from 4 to 3. Each of those remaining 3 bikes had their distinct geometry, personality, and purpose, while maintaining similar distances between the contact points.
|
I stumbled upon this frame at a great price on eBay in April 2018. It was offered by a vendor in Scotts Valley. I have a weakness for Merckx bikes and this is very different from my other bikes. It has disc brakes, but has road geometry not gravel/touring angles. It is set up for internal di2 routing and the reviews said it was a phenomenal descending bikes. I could not resist.
|
I purchased this frame used on eBay in 2005.
The tubing is a combination of 6AL/4V and 3AL/2.3V titanium, with many tubes being shaped.
Of particular note is the huge, aero 6/4 downtube.
This frame was built to Eddie Merckx's specs by Lightspeed.
The decals were in pretty bad shape when I bought the frame, so I replaced them.
Since I could not find replacement decals that match the originals, I used decals for a Merckx Ti AX frame. |
| Picture |
 |
 |
 |
 |
| Geometry |
Frame Size: 61cm
Seat Tube c-t: 610mm
Horizantal Top Tube: 608mm
Head Tube: 214mm
Wheelbase: 1063mm
BB Drop: 73.5mm
Chainstays: 420mm
Head Tube Angle: 72 degrees
Seat Tube Angle: 73 degrees
Stack: 630mm
Reach: 415mm
|
Frame Size:XXL
Seat Tube c-t: 595mm
Horizantal Top Tube: 591mm
Head Tube: 215mm
Wheelbase: 1036mm
BB Drop: 75mm
Chainstays: 415mm
Head Tube Angle: 72.5 degrees
Seat Tube Angle: 73.5 degrees
Stack: 630mm
Reach: 404mm
|
Frame Size: XXL
Seat Tube c-t: 570mm
Horizantal Top Tube: 588mm
Head Tube: 231mm
Wheelbase: 1016mm
BB Drop: 68mm
Chainstays: 412mm
Head Tube Angle: 73.2 degrees
Seat Tube Angle: 73 degrees
Stack: 631mm
Reach: 395mm
|
Frame Size: 61cm
Seat Tube c-t: 630mm
Horizontal Top Tube: 588mm
Head Tube: ??
Wheelbase: ??
BB Drop: ??
Chainstays: ??
Head Tube Angle: 73 degrees
Seat Tube Angle: 72 degrees
Stack: ??
Reach: ??
|
| Weight |
?? lbs |
18.49 lbs |
18.67 lbs |
18.29 lbs |
| Frame |
Carbon |
Carbon SL |
Monocoque Carbon |
Combination of 3.25 and 6/4 Titanium |
| Fork |
Cervelo Carbon, 46/51mm rake |
Focus Carbon, 46mm rake |
Eddy Merckx, 43mm rake |
Enve 2.0, 43mm rake |
| Headset |
FSA IS2 1.23 x 1.5 in |
Cane Creek 110 IS42/28.6 tall top
FSA IS47/33 bottom |
Merckx - tall top cap |
Chris King 1.125 NoThreadSet, black Sotto Voce
25mm spacers |
| Stem |
Zipp Service Course SL
11cm, -6 degrees, beyond black |
Enve Carbon
13cm, -6 degrees, black decals |
Enve Carbon
13cm, -6 degrees, black decals |
Zipp Service Course SL
13cm, -6 degrees, beyond black |
| Handlebars |
Vision Metron 4D Carbon Compact - 44cm |
Vision Metron 4D Carbon Compact - 44cm |
Vision Metron 4D Carbon Compact - 44cm |
Vision Metron 4D Carbon Compact - 44cm |
| Bar Tape |
Fizik Performance Tacky 3.0mm - Black |
Fizik Performance Tacky 3.0mm - Black |
Fizik Performance Tacky 3.0mm - Black |
Fizik Performance Tacky 3.0mm - Black |
| Brake Levers |
SRAM Force AXS HRD |
Shimano Ultregra 8070 |
SRAM Force AXS HRD |
SRAM Red AXS |
| Brake Calipers |
SRAM Force Flat Mount
Swiss Stop Centerlock 160mm Rotors |
Shimano Ultegra 8070 Flat Mount
Shimano RT-800 160mm Rotors |
SRAM Force Flat Mount
SRAM Centerline XR Centerlock 160mm Rotors |
SRAM Red |
| Buttom Bracket |
BBInfinite BBRight, Ceramitech Bearings, 30mm, DUB Inserts |
Token Ninja Ceramic PF30 |
Chris King Press Fit 24 - Black BB86 |
SRAM DUB, ITA |
| Crankset |
SRAM Force - 177.5mm, GXP
Quarq DZero Power Meter
Absolute Black Gravel Oval, 44t |
SRAM Force 1 - 177.5mm, BB30
Absolute Black Gravel Oval, 44t
Wahoo RPM cadence sensor |
SRAM Force - 177.5mm, GXP
Quarq DZero Power Meter
Absolute Black Gravel Oval, 44t |
Quarq Carbon - 177.5mm, DUB
Quarq DZero Power Meter
Absolute Black Gravel Oval 1X, 44t |
| Pedals |
Shimano XTR PD-M9000 Race SPD |
Shimano XTR PD-M9000 Race SPD |
Shimano XTR PD-M9000 Race SPD |
Shimano XTR PD-M9000 Race SPD |
| Front Derailleur |
None |
None |
None |
None |
| Rear Derailleur |
SRAM Rival XPLR |
Shimano XT M8050 - GS |
SRAM Rival XPLR |
SRAM Force XPLR |
| Chain |
SRAM Force 12 speed Flat Top |
SRAM Red22 |
SRAM Force 12 speed Flat Top |
SRAM Force 12 speed Flat Top |
| Cassette |
SRAM XG-1251- 10/44 |
SRAM XG-1199- 10/42 |
SRAM XG-1271 - 11/44 |
SRAM XG-1271 - 11/44 |
| Front Wheel |
White Industries CLD black hub, 100mm QR
November All Road 50 rim
28 black Sapim CX-Sprint spokes
black alloy nipples |
DT Swiss 350 straight pull hub, 100x12mm
Light Bike RR46C02 rim
28 black Sapim CX-Ray spokes
black brass nipples |
DT Swiss 350 straight pull hub, 100x12mm
Light Bike RR56C02 rim
28 black Sapim CX-Ray spokes
black brass nipples |
DT Swiss 350 straight pull hub, 100mm QR
HED Belgium Plus rim
24 black Sapim CX-Ray spokes
black brass nipples w/ Sapim HM washers |
| Rear Wheel |
White Industries CLD black hub, 135mm QR, HG11
November All Road 50 rim
28 black Sapim CX-Sprint spokes
black alloy nipples |
White Industries CLD black hub, 12x142mm, XDR
Light Bike RR46C02 rim
28 black Sapim CX-Sprint spokes
black brass nipples |
Onyx Vesper black hub, 12x142mm, XDR
Light Bike RR56C02 rim
28 black Sapim CX-Sprint spokes
black brass nipples |
Onyx Vesper black chrome hub, 130mm QR, XDR
HED Belgium Plus rim
32 Sapim Race black
black brass nipples w/ Sapim HM washers |
| Quick Release |
Cervelo 12mm |
Roberts Axle Project 12mm thru axle |
Merckx 12mm thru axle |
Shimano Dura Ace 9000 |
| Tires |
Continental Grand Prix 5000 AS TR - 35mm |
Michelin Power Road TS TLR - 32mm |
Hutchinson Fusion 5 Performance Tubeless - 30mm |
Hutchinson Fusion 5 Performance Tubeless - 28mm |
| Seatpost |
Ritchey Superlogic 1-bolt
27.2 x 350, 25mm setback |
Enve 2-bolt
25.4mm, 25mm setback |
Merckx |
Lynisky Ti
27.2 x 300, 25mm setback |
| Seatpost Clamp |
Campagnolo 28.6 |
Focus |
built into frame |
Ti Works 31.8mm |
| Saddle |
Fizik Antares R1 - Large. Black, Carbon Rails |
Fizik Antares R1 - Large. Black, Carbon Rails |
Fizik Antares R1 - Large. Black, Carbon Rails |
Fizik Antares R1 - Large. Black, Carbon Rails |
| Computer |
Wahoo Elemnt - Zipp Quickview mount |
Wahoo Elemnt - Enve V2 mount |
Wahoo Elemnt - Enve V2 mount |
Wahoo Elemnt - Zipp Quickview mount |
| Bottle Cages |
Arundel Mandible, gloss 3k |
Arundel Mandible, gloss 3k |
Arundel Mandible, matte 3k |
Arundel Mandible, gloss 3k |
| Pump |
Lezyne Road Drive - large, black |
Lezyne Road Drive - large, black |
Lezyne Road Drive - large, carbon |
Blackburn Carbon Frame Pump - XL |
